序

本文主要研究一下flink KeyedStream的KeySelector

KeyedStream

flink-streaming-java_2.11-1.7.0-sources.jar!/org/apache/flink/streaming/api/datastream/KeyedStream.java

@Publicpublic class KeyedStream

      extends DataStream

       {	/**	 * The key selector that can get the key by which the stream if partitioned from the elements.	 */	private final KeySelector

        keySelector;	/** The type of the key by which the stream is partitioned. */	private final TypeInformation

         keyType;	/**	 * Creates a new {@link KeyedStream} using the given {@link KeySelector}	 * to partition operator state by key.	 *	 * @param dataStream	 *            Base stream of data	 * @param keySelector	 *            Function for determining state partitions	 */	public KeyedStream(DataStream

          dataStream, KeySelector

           keySelector) { this(dataStream, keySelector, TypeExtractor.getKeySelectorTypes(keySelector, dataStream.getType())); } /** * Creates a new {@link KeyedStream} using the given {@link KeySelector} * to partition operator state by key. * * @param dataStream * Base stream of data * @param keySelector * Function for determining state partitions */ public KeyedStream(DataStream

            dataStream, KeySelector

             keySelector, TypeInformation

              keyType) { this( dataStream, new PartitionTransformation<>( dataStream.getTransformation(), new KeyGroupStreamPartitioner<>(keySelector, StreamGraphGenerator.DEFAULT_LOWER_BOUND_MAX_PARALLELISM)), keySelector, keyType); } /** * Creates a new {@link KeyedStream} using the given {@link KeySelector} and {@link TypeInformation} * to partition operator state by key, where the partitioning is defined by a {@link PartitionTransformation}. * * @param stream * Base stream of data * @param partitionTransformation * Function that determines how the keys are distributed to downstream operator(s) * @param keySelector * Function to extract keys from the base stream * @param keyType * Defines the type of the extracted keys */ @Internal KeyedStream( DataStream

               stream, PartitionTransformation

                partitionTransformation, KeySelector

                 keySelector, TypeInformation

                  keyType) { super(stream.getExecutionEnvironment(), partitionTransformation); this.keySelector = clean(keySelector); this.keyType = validateKeyType(keyType); } //......}复制代码

这里可以看到KeyedStream的不同构造器中都需要一个KeySelector类型的参数

KeySelector

flink-core-1.7.0-sources.jar!/org/apache/flink/api/java/functions/KeySelector.java

@Public@FunctionalInterfacepublic interface KeySelector

      extends Function, Serializable {	/**	 * User-defined function that deterministically extracts the key from an object.	 *	 *
     For example for a class:	 *
     	 * 	public class Word {	 * 		String word;	 * 		int count;	 * 	}	 *
	 * The key extractor could return the word as	 * a key to group all Word objects by the String they contain.	 *	 *
     The code would look like this	 *
     	 * 	public String getKey(Word w) {	 * 		return w.word;	 * 	}	 *
	 *	 * @param value The object to get the key from.	 * @return The extracted key.	 *	 * @throws Exception Throwing an exception will cause the execution of the respective task to fail,	 *                   and trigger recovery or cancellation of the program.	 */	KEY getKey(IN value) throws Exception;}复制代码

KeySelector接口继承了Function接口，定义了getKey方法，用于从IN类型中提取出KEY

DataStream.keyBy

flink-streaming-java_2.11-1.7.0-sources.jar!/org/apache/flink/streaming/api/datastream/DataStream.java

/**	 * It creates a new {@link KeyedStream} that uses the provided key for partitioning	 * its operator states.	 *	 * @param key	 *            The KeySelector to be used for extracting the key for partitioning	 * @return The {@link DataStream} with partitioned state (i.e. KeyedStream)	 */	public

      KeyedStream

       keyBy(KeySelector

        key) {		Preconditions.checkNotNull(key);		return new KeyedStream<>(this, clean(key));	}	/**	 * It creates a new {@link KeyedStream} that uses the provided key with explicit type information	 * for partitioning its operator states.	 *	 * @param key The KeySelector to be used for extracting the key for partitioning.	 * @param keyType The type information describing the key type.	 * @return The {@link DataStream} with partitioned state (i.e. KeyedStream)	 */	public

         KeyedStream

          keyBy(KeySelector

           key, TypeInformation

            keyType) { Preconditions.checkNotNull(key); Preconditions.checkNotNull(keyType); return new KeyedStream<>(this, clean(key), keyType); } /** * Partitions the operator state of a {@link DataStream} by the given key positions. * * @param fields * The position of the fields on which the {@link DataStream} * will be grouped. * @return The {@link DataStream} with partitioned state (i.e. KeyedStream) */ public KeyedStream

             keyBy(int... fields) { if (getType() instanceof BasicArrayTypeInfo || getType() instanceof PrimitiveArrayTypeInfo) { return keyBy(KeySelectorUtil.getSelectorForArray(fields, getType())); } else { return keyBy(new Keys.ExpressionKeys<>(fields, getType())); } } /** * Partitions the operator state of a {@link DataStream} using field expressions. * A field expression is either the name of a public field or a getter method with parentheses * of the {@link DataStream}'s underlying type. A dot can be used to drill * down into objects, as in {@code "field1.getInnerField2()" }. * * @param fields * One or more field expressions on which the state of the {@link DataStream} operators will be * partitioned. * @return The {@link DataStream} with partitioned state (i.e. KeyedStream) **/ public KeyedStream

              keyBy(String... fields) { return keyBy(new Keys.ExpressionKeys<>(fields, getType())); } private KeyedStream

               keyBy(Keys

                keys) { return new KeyedStream<>(this, clean(KeySelectorUtil.getSelectorForKeys(keys, getType(), getExecutionConfig()))); }复制代码

DataStream的keyBy方法用于将DataStream转换为KeyedStream，该方法有不同的重载

一个是支持变长int数组，这个通常用于简单tuple类型，int为tuple的小标，从0开始，如果是多个int，表示是组合key，比如keyBy(0,1)表示要用tuple的第一个和第二个字段作为key；

一个是支持变长String数组，这个通常用于复杂tuple类型及POJO类型，对于POJO，String用于指定字段名，也支持对象/tuple嵌套属性，比如user.zip，对于对象类型的tuple，f0表示该tuple的第一个字段

一个是支持KeySelector，通过Key Selector Function可以自由指定key，比如从对象提取然后做些处理

keyBy(int... fields)及keyBy(String... fields)里头均有调用到私有的keyBy(Keys<T> keys)方法，由于KeyedStream的构造器都需要KeySelector参数，所以该方法最后也是通过KeySelectorUtil.getSelectorForKeys将Keys转换为KeySelector对象

Keys.ExpressionKeys

flink-core-1.7.0-sources.jar!/org/apache/flink/api/common/operators/Keys.java

/**	 * Represents (nested) field access through string and integer-based keys	 */	public static class ExpressionKeys

      extends Keys

       {				public static final String SELECT_ALL_CHAR = "*";		public static final String SELECT_ALL_CHAR_SCALA = "_";		private static final Pattern WILD_CARD_REGEX = Pattern.compile("[\\.]?("				+ "\\" + SELECT_ALL_CHAR + "|"				+ "\\" + SELECT_ALL_CHAR_SCALA +")$");		// Flattened fields representing keys fields		private List

        keyFields;		private TypeInformation
       [] originalKeyTypes;		//......		/**		 * Create String-based (nested) field expression keys on a composite type.		 */		public ExpressionKeys(String[] keyExpressions, TypeInformation

         type) {			checkNotNull(keyExpressions, "Field expression cannot be null.");			this.keyFields = new ArrayList<>(keyExpressions.length);			if (type instanceof CompositeType){				CompositeType

          cType = (CompositeType

          ) type; this.originalKeyTypes = new TypeInformation
          [keyExpressions.length]; // extract the keys on their flat position for (int i = 0; i < keyExpressions.length; i++) { String keyExpr = keyExpressions[i]; if (keyExpr == null) { throw new InvalidProgramException("Expression key may not be null."); } // strip off whitespace keyExpr = keyExpr.trim(); List

            flatFields = cType.getFlatFields(keyExpr); if (flatFields.size() == 0) { throw new InvalidProgramException("Unable to extract key from expression '" + keyExpr + "' on key " + cType); } // check if all nested fields can be used as keys for (FlatFieldDescriptor field : flatFields) { if (!field.getType().isKeyType()) { throw new InvalidProgramException("This type (" + field.getType() + ") cannot be used as key."); } } // add flat fields to key fields keyFields.addAll(flatFields); String strippedKeyExpr = WILD_CARD_REGEX.matcher(keyExpr).replaceAll(""); if (strippedKeyExpr.isEmpty()) { this.originalKeyTypes[i] = type; } else { this.originalKeyTypes[i] = cType.getTypeAt(strippedKeyExpr); } } } else { if (!type.isKeyType()) { throw new InvalidProgramException("This type (" + type + ") cannot be used as key."); } // check that all key expressions are valid for (String keyExpr : keyExpressions) { if (keyExpr == null) { throw new InvalidProgramException("Expression key may not be null."); } // strip off whitespace keyExpr = keyExpr.trim(); // check that full type is addressed if (!(SELECT_ALL_CHAR.equals(keyExpr) || SELECT_ALL_CHAR_SCALA.equals(keyExpr))) { throw new InvalidProgramException( "Field expression must be equal to '" + SELECT_ALL_CHAR + "' or '" + SELECT_ALL_CHAR_SCALA + "' for non-composite types."); } // add full type as key keyFields.add(new FlatFieldDescriptor(0, type)); } this.originalKeyTypes = new TypeInformation[] { type}; } } //...... }复制代码

ExpressionKeys是Keys里头的一个静态类，它继承了Keys对象；keyBy(int... fields)及keyBy(String... fields)里头均有通过new Keys.ExpressionKeys，将fields转换为Keys.ExpressionKeys，最后调用私有的keyBy(Keys<T> keys)方法

KeySelectorUtil.getSelectorForKeys

flink-streaming-java_2.11-1.7.0-sources.jar!/org/apache/flink/streaming/util/keys/KeySelectorUtil.java

@Internalpublic final class KeySelectorUtil {	public static

      KeySelector

       getSelectorForKeys(Keys

        keys, TypeInformation

         typeInfo, ExecutionConfig executionConfig) {		if (!(typeInfo instanceof CompositeType)) {			throw new InvalidTypesException(					"This key operation requires a composite type such as Tuples, POJOs, or Case Classes.");		}		CompositeType

          compositeType = (CompositeType

          ) typeInfo; int[] logicalKeyPositions = keys.computeLogicalKeyPositions(); int numKeyFields = logicalKeyPositions.length; TypeInformation
          [] typeInfos = keys.getKeyFieldTypes(); // use ascending order here, the code paths for that are usually a slight bit faster boolean[] orders = new boolean[numKeyFields]; for (int i = 0; i < numKeyFields; i++) { orders[i] = true; } TypeComparator

            comparator = compositeType.createComparator(logicalKeyPositions, orders, 0, executionConfig); return new ComparableKeySelector<>(comparator, numKeyFields, new TupleTypeInfo<>(typeInfos)); } //......}复制代码

KeySelectorUtil.getSelectorForKeys方法用于将Keys转换为KeySelector类型

小结

KeyedStream的不同构造器中都需要一个KeySelector参数

DataStream的keyBy方法有不同的重载，支持变长int数组，变长String数组以及KeySelector类型

keyBy(int... fields)及keyBy(String... fields)里头均有通过new Keys.ExpressionKeys，将fields转换为Keys.ExpressionKeys，最后调用私有的keyBy(Keys<T> keys)方法，该方法通过调用KeySelectorUtil.getSelectorForKeys方法将Keys转换为KeySelector类型
